SENSIT® GOLD 3 GLT
Specs
Product Specification
| Size | L-13 x W-3 x D-3.2 in (330 x 76 x 81 mm) |
| Weight | 2.3lbs (1.0kg) |
| Operating Temperature | -4 to 122° F (-20 to 50° C) |
| Storage Temperature | -4 to 140°F (-20 to 60° C) |
| Battery Life | >20hrs Continuous with Rechargeable |
| Recharge Time | 10hrs Max |
| Recharge Temperature | 32°F to 104°F (0°C to 40°C) |
| Environmental Protection | IP64 |
| Display | 2.7” TFT LCD |
| Standard Kit | Soft-Sided, Padded Pouch Vehicle/Desktop Charger Wall Transformer or Vehicle Aux Cord Rechargeable Battery Extra Sensor Cap Wrist Strap Instruction Manual |
| Optional Accessories | GPS with 3M Accuracy Extension Adapter Belt Clip Carrying Strap (Additional Hardware Required) |
Additional Features
| Quick Menu | Tick Barhole Purge Test Leak Search Peak Mode Stand By CF Test CO Test Confined Space Mode Inert Mode |
| Barhole Test Features | Peak Readings Sustained Readings 30 Second Test Automatic Barhole Test Purge Test Data Saved to Memory |
| Configurable Calibration Reminders | Next Calibration Due Last Calibration Calibration Over-Due Days Remaining Until Calibration Due Calibration Required Lockout |
| Gas Specification | “NSR” - Non-Standard Response “NSC” - Non-Standard Combustible |
Sensor Specifications
| Type | Technology | Resolution | Range | Accuracy |
| LEL | Semiconductor | Variable: 0.1% - 2.0% Increments | 0-100% LEL | ±10% or 1%LEL* |
| PPM* | Semiconductor | 1 ppm or 10 ppm | 0 – 50,000 ppm | ±10% or 500ppm* |
| % NAT GAS | Thermal Conductivity | 0.1% | 5 – 100% Methane | ±5% |
| Propane | Thermal Conductivity | 0.1% | 2.2 – 100% Propane | ±5% |
| O2 | Electrochemical | 0.1% | 0-25% | ±0.2% or 10%** |
| CO | Electrochemical | 1PPM | 0-2,000PPM | ±5PPM or 5%** |
| H2S | Electrochemical | 1ppm or 0.1ppm | 0-100PPM | ±2PPM or 5%** |
| HCN | Electrochemical | 1ppm or 0.1ppm | 0-30PPM | ±1PPM or 5%** |
| SO2 | Electrochemical | 0.1ppm | 0-20PPM | ±1PPM or 10%** |
*PPM Optional
**Whichever is greater
