SENSIT® HXG-3P

SENSIT^® HXG-3 available certifications

ATEX | NOTE – This gas detector is only available for areas requiring an ATEX certification.

SENSIT^® HXG-3P measures combustible gases such as methane, propane, natural gas, pentane and other volatile organic compounds (VOCs). The backlit LCD display shows percent lower explosive limit (LEL) and part-per million (ppm) readings simultaneously. Audible and visual alarms warn of potential hazardous conditions.

SENSIT^® HXG-3P also features our unique audible tick control that helps find the source of gas leaks fast. The tick can be easily heard through the speaker located in the back of the instrument.

SENSIT^® HXG-3p is Combustible Gas Leak Detector displays %LEL and PPM simultaneously.
LEL Range 0-100% LEL
PPM Range 0-50,000 ppm

Compatible with:

Request a Quote

Categories: All, Combustible Gas Leak Detectors, Explosive Gas Meters Tags: Environmental, HVAC and Plumbing Industries, Industrial Health & Safety, Municipal & Government, Natural Gas Energy Industry, Propane, Public Safety Industries, UL Certified

Description

PARTIAL LIST OF GASES DETECTED
Acetone
Alcohol
Ammonia
Butane
Gasoline
Halon
Hydrogen
Jet Fuel
Ethylene Oxide
Methane
Natural Gas
Propane
Refrigerants
Solvents

STANDARD FEATURES
Intrinsically Safe Design (Certified)
Long-life, Low-Cost Sensor
Internal Pump
Water/Dust Filter
Displays LEL and PPM
Audible/Visual Alarms
Infrared Downloading
Simple Calibration

Certifications
ATEX
UL

Specs

Product Specification

Size	11.5” x 3” x 2.32” (29.2 x 7.6 x 5.9 cm)
Weight	1.2 lb. (544 g)
Operating Temperature	0 to 120 F (-17.8 to 48.8° C)
Battery Life	Alkaline: Approximately 12 hrs. Continuous
Standard Kit	Hard Carrying Case, 3 “C” Batteries, Extra Sensor Cap, Wrist Strap, Instruction Manual
Optional Accessories	Recharger Kit, Printer, PC Interface, Hot Air Probe, Confined Space Probe, Calibration Kit

sensor Specifications

Type	Resolution	Range	Accuracy
LEL	0.1%	0-100% LEL	±10%
PPM*	1 or 10 PPM	0-50,000 PPM	±10%

*PPM Optional
