SCAL-400 Calibration

This product is no longer being manufactured, however we will continue to service and support the unit.

Category: Discontinued

Description

Design to Test/Calibrate SENSIT^® P400 Monitors

Methane - CH4
Oxygen - O2
Carbon Monoxide - CO
Hydogen Sulfide - H2S
Hydrogen Cyanide - HCN
Nitrogen Dioxide - NO2
Sulfure Dioxide - SO2

STANDARD FEATURES
Touch Screen Operation
Test/Charge up to 5 P400’s Simultaneously
Auto Operation when Instrument is Installed
Indication of Pass or Fail
RJ45 Intranet Connection/Serial
Gas Bottle Supply Monitoring
Configurable Valves
Wireless Firmware Updates Pushed To Devices
Wi-Fi/LAN Equipped (Network Stations)
Compatible with Windows 7, 8, 8.1, 10
Windows Server 2008, 2008 R2, 2012, 2012 R2, 2016, 2019

Reporting Features
Instrument Test Past Due
Instrument Failure Alerts
Monthly Compliance Report
Sensor Performance Data
Optional Networking System
SMARTLINK/ SMARTLINK 360

Compatible with
SCAL-D 360 (Desktop)
SCAL-N 360 (Network)
Data Management Software

Specs

Product Specification

Size	24” x 7” x 3” (61cm x 17.8cm x 7.6cm)
Weight	5.75 lb. (2.6 kg)
Operating Temperature	40 – 122 F (5 to 50° C)
MAX. Inlet Pressure	20 PSI
Power Requirement	100-240 VAC

Software Requirements

1 GB Hard Drive Space
Windows® Operating System: 7, 8, 8.1, 10
Windows® Server: 2008, 2008 R2, 2012, 2012 R2, 2016, 2019
Microsoft® Outlook (Preferred. Not Required)
Microsoft® Excel (Preferred. Not Required)

SCAL-360 DATA MANAGEMENT SOFTWARE (Sold Separately)

SCAL-D 360 is the Desktop version of the software. Various reports and alerts can be viewed, printed, emailed, or stored as an Excel spreadsheet. When configured, it will automatically alert operators and supervisors of important data depending on their preference.

SCAL-N 360 is the Network version of the software. Use SCAL-N 360 to download data from remotely located Calibration Station(s). Data is stored in the SQL Server.
