SMART-CAL 360

SMART-CAL 360 takes calibrating SENSIT® instruments to the next level.

In addition to logging calibration data, time, date, sensor and pump performance, SMART-CAL 360 pushes firmware updates to selected SENSIT instruments without the need to return the instrument to the factory. SMART-CAL 360 tracks sensor life, and gives an early warning when it’s time to replace calibration bottles.

Improved data management software provides automatic data transfer for compliance reports and notifications of overdue or failed calibrations. Logs can be viewed on the large touchscreen display or reports via emailed spreadsheet or pdf. SMART-CAL 360 communicates over LAN and Wi-Fi, so that the station can be positioned where it is most convenient and accessible, and it works with any SMART-CAL compatible instrument.

Designed for use with:
CO
GOLD
GOLD 100
GOLD CGI
GOLD EX/CO+ 1200
GOLD G2
GOLD G3
HCN
HXG-3
HXG-3P
IRED
PMD
PMD2
TRAK-IT® IIIa
Compatible with:
Request a Quote



Description

AVAILABLE TEST GASES (Contact Sensit Technologies for more information.)
PPM (Methane)
LEL (Methane)
LEL (Propane)
% Volume (Methane)
Carbon Monoxide – CO<
Hydrogen Cyanide – HCN
Hydrogen Sulfide – H2S
Nitrogen – N2
Ethane – C2H6


STANDARD FEATURES
7” Touchscreen
IR/NFC/Bluetooth Communications
Automatic Upload of Records
Calibration/Bump Memory Storage
SD Card – Database Backup | Configuration Backup | Station Firmware Updates
Gas Bottle Supply Monitoring
Configurable Valves
Wireless Firmware Updates Pushed To Devices
Wi-Fi/LAN Equipped (Network Stations)
USB (Desktop Stations)
Filtered/Replaceable Gas Port Connections
LED Status Indicator
(Busy, Ready, Pass, Fail, Check Gas Supply)
Automatic Date Adjustment


Reporting Features
Instrument Test Past Due
Instrument Failure Alerts
Monthly Compliance Report
Custom Reports
Service Reports
Calibration Gas Expiration Reports
Compatible with
SCAL-D 360 (Desktop)
SCAL-N 360 (Network)
Data Management Software


Text alerts
Test Due Alerts
SCAL-D/N 360 Data Management Software Compatible with SMART-CAL 360, SMART-CAL, SCAL-100, SCAL-400
